LBL Lighting Omni Medium CF User Manual
Medium omni (compact fluorescent), Prepare the fixture for installation, Installation instructions for

Installation Instructions for
Medium Omni (Compact Fluorescent)
1.0
PW561, PW564
980OMNIMWOCF
1
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for damp locations.
This product can mount to either a 4" square electrical box with
round plaster ring or an octagon electrical box.
Remove the eight cap screws around the perimeter of the cover.
Lift the cover off the fixture body.
Prepare the Fixture for Installation
Remove the six screws on the reflector.
Lift the reflector out of the fixture body.
Outdoor
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
