Install the lamp and cover, 3b 3a 2f 2e – LBL Lighting Omni Small CF User Manual
Page 3
3B
3A
2F
2E
Connect the white wire to the neutral power line wire.
Connect the black wire to the hot power line wire.
Reinstall the reflector into the housing and tighten all four
screws to hold it in place.
Install the Lamp and Cover
LAMP
SOCKET
Reinstall all the cap screws around the perimeter of the cover.
3
9
10
11
1
2
Push the lamp base into the socket.
9
10
11
11
11
11
2
2
2
2
2
2
Use
18 Watt GX24Q-2 Base
Triple Tube Compact Fluorescent Lamp.
MAX
