LBL Lighting Windfall User Manual
Windfall outdoor, Install the fixture
1
Installation Instructions for
Windfall Outdoor
980WINDFO
Install the Fixture
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for wet locations.
This product can mount either to a 4” square electrical box with a
round plaster ring or an octagon electrical box.
This product may be dimmed with a low-voltage electronic dimmer.
This instruction shows a typical installation.
Remove the two fixture screws located on the top and
bottom of the fixture base.
Remove the mounting plate from the fixture.
Attach the mounting plate to the electrical box using
the two #8-32 screws provided.
MOUNTING
PLATE
FIXTURE SCREW
1
1A
2
Outdoor
1.0
OD785_
3
1
1
#8-32 SCREW
1B
3
3
MOUNTING
PLATE
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
