LBL Lighting Rock Candy 3-Light - Manual

Installation Instructions for
Rock Candy 3-Light Bath
980ROCKC3W
Install the Mounting Plate
G P I : ENERAL RODUCT NFORMATION
This product is suitable for damp locations.
This product can mount either to a 4” square electrical box with a
round plaster ring or an octagon electrical box.
This product can be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Wall
1.0
BA7513_
1
Remove the two Allen screws located on the bottom of
the fixture base using the Allen wrench provided.
Remove the mounting plate by sliding it away from the
mounting studs then out of the fixture.
Attach the mounting plate to the electrical box using
the two #8-32 screws provided. 1
2
3
TOP VIEW
MOUNTING STUD
MOUNTING
PLATE
ALLEN SCREW
1A
1 1
2 2
2
MOUNTING
PLATE
#8-32 SCREW
1B
3
3
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
ALLEN WRENCH
