Install the lamp and cover, Max 39 watt – LBL Lighting Final Call Medium User Manual
Page 3
3
2B
1
Re-install the front cover and secure it tightly with the
two fixture screws using the Allen wrench.
2
ALLEN WRENCH
FIXTURE
SCREW
2
FIXTURE
SCREW
FRONT
COVER
2A
1
1
Line up the lamp pins into the sockets and rotate the
lamps to lock it in place.
use
type T5 high output linear
fluorescent lamp.
MAX 39 Watt
CAUTION: To reduce the risk of a burn or electric
shock during relamping, disconnect the power to
the fixture.
LAMP
LAMP SOCKET
LAMP SOCKET
1
1
2
Install the Lamp and Cover
NOTE: To re-lamp, reverse figures 2A and 2B or
simply reach inside the fixture if possible.
NOTE: To re-lamp, reverse section 2.
