Installation Instructions for
Rania Bath (LED)
980RANIAWD
G P I : ENERAL RODUCT NFORMATION
This product is suitable for damp locations.
This product can mount either to a 4” square electrical box with a
round plaster ring or an octagon electrical box.
May be dimmed with a low-voltage electronic dimmer.
This instruction shows a typical installation.
1.0
BA823_LED
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1B
Wall
Remove the bracket screws located on the top and
bottom of the fixture base.
Remove the brackets from the fixture base.
1
2
1A
BRACKET
SCREW
1
1
BRACKET
Remove the fixture screws located on the top and
bottom of the fixture base.
Remove the mounting plate from the fixture base.
3
FIXTURE SCREW
4
3
3
FIXTURE SCREW
MOUNTING PLATE
Install the Mounting Plate
