LBL Lighting Mono-Tel User Manual
Mono-arc and mono-tel, Install the fixture install the lamp

1
Place one fixture connector slot from the top and the other
one from the bottom onto the MonoRail.
Installation Instructions for
Mono-Arc and Mono-Tel
1.0
HPARC_MRL, HPTEL_MRL
980WMARCTEL
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for indoor dry locations only.
This product must be used with LBL Lighting Wall MonoRail system
only.
SLOT
MONORAIL
FIXTURE
CONNECTOR
Install the Fixture
Install the Lamp
Push the lamp pins completely into the socket.
LAMP PIN
SOCKET
C AUTION:To reduce the risk of a burn or electric
shock during relamping, disconnect the power to the
fixture.
Use
MR16 Front Cover Halogen
MAX 50 Watt
Lamp.
NOTE:
Use only your fingers and a soft cloth to replace
the lamp.
Wall Monorail
1A
1
1
2A
1
1
1
