LBL Lighting Vision Chandelier - Manual

Installation Instructions for
Visions Chandelier Head 1.3 HA336_1A35MRL
980MRLVISNCH
GENERAL PRODUCT INFORMATION:
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
This product is intended to be used with LBL Monorail system.
1
Install the Lamp and Disk
LAMP
SOCKET
Align and push the lamp pins completely into the socket holes.
Orient the recessed section of the crystal glass disk towards
the lamp. Place edge of the crystal disk into curved section of
accessory springs.
Use MAX 35 Watt MR11 Front Cover Halogen
Lamp .
CURVED
SECTION
CRYSTAL
GLASS DISK
ACCESSORY
SPRINGS
CURVED
SECTION
NOTE: The Crystal disk must be removed when relamping.
NOTE: To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
Monorail
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1A 1A
1
1
1A 1B
2
2
2
2
2
