Install the Lamp and Shade
Push the lamp base into the socket.
LAMP
SOCKET
Use
Type Twin Tube T5,
MAX 24 Watt
2G11 Base Compact Fluorescent Lamp.
SHADE
SUPPORT ARM
SUPPORT ARM
ALLEN WRENCH
Use the Allen wrench to remove the upper shade support arm.
Place the shade into the slot in the lower shade support arm.
Line up the slot in the upper shade support arm with the top
of the shade.
Use the Allen wrench to attach the shade support arm to the
top of the fixture.
1
2
3
4
5
5
3
4
