Install the lamp and shade, 2b 2a – LBL Lighting Omni w/Cover Medium User Manual
Page 3
2B
2A
3
Install the Lamp and Shade
Use
Volt,
Type BT15
MAX
60
120
Watt
Medium Base Lamp in each socket.
Screw a lamp into each socket.
LAMP
SOCKET
SHADE
SUPPORT ARM
SUPPORT ARM
ALLEN WRENCH
Use the Allen wrench to remove the upper shade support arm.
Place the shade into the slot in the lower shade support arm.
Line up the slot in the upper shade support arm with the top
of the shade.
Use the Allen wrench to attach the shade support arm to the
top of the fixture.
1
2
3
4
5
5
3
4
