LBL Lighting Dahling W User Manual
Dahling wall, Install the fixture
1
Installation Instructions for
Dahling Wall
980DHLNGW
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
Install the Fixture
1.1
LF622GO_2D
1A
Connect the mounting plate ground wire to a suitable
ground according to local electrical codes.
Connect the white fixture wire to the neutral power line
wire with a wire nut.
Connect the black fixture wire to the hot power line
wire with a wire nut.
1
2
3
4
4
3
2
1
Attach the mounting plate to the electrical box using
the two #8-32 screws provided.
4
Wall
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for damp locations.
This product can mount either to a 4” square electrical box with a
round plaster ring or an octagon electrical box.
This product can be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
