LBL Lighting Voti Accessory User Manual
Voti accessory, Install the accessory, Save these instructions

Installation Instructions for
Voti Accessory
1.1
HAC482_
980DOMEGACC
Accessories
Install the Accessory
If the accessory fits tight onto the fixture, then carefully
bend the grooved shade holder tabs in slightly with the
needlenose pliers. If it fits loose, then carefully bend the
grooved shade holder tabs out slightly with the
needlenose pliers.
G
P
I
:
ENERAL RODUCT NFORMATION
This product must be used with LBL Lighting systems only.
Use MAX 50 Watt MR16 Front Cover Halogen
Lamp.
Place the MR16 lamp into the glass shield with attached
louver base.
Place the louver or glass lens on front of the MR16
lamp.
Screw the louver holder cap completely onto the louver
base.
1
Line up the lamp pins with the socket holes.
Push the accessory base onto the grooved shade holder.
GROOVED
SHADE HOLDER
ACCESSORY
ACCESSORY BASE
ROUND OR CONE
GLASS SHIELD WITH
ATTACHED LOUVER BASE
MR16 LAMP
LOUVER OR
GLASS LENS
LOUVER HOLDER CAP
GROOVED SHADE
HOLDER TAB
1
1A
1A
1A
1C
1A
1B
1
2
3
4
6
5
4
6
3
2
