Installation Instructions for
Puck Swivel
1.6
HE437SC_1A50FSJ
980FSJPUCS
Install the Lamp
1
Place the AR111 lamp into the cap.
Squeeze the spring ends and place it into the groove inside the
cap to hold the AR111 lamp in place.
Release the spring ends.
Use
50 Watt,AR111 (PAR36) Halogen
MAX
Lamp.
NOTE:
To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
LAMP
SPRING END
CAP
Loosen
the #8-32 screws on the lamp
(Do Not Remove)
bracket.
Slide the fixture bracket slots under the #8-32 screws.
#8/32 SCREW
FIXTURE
BRACKET
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
Fusion Jack
™
1A
5
WARNING:
Risk of Fire. Hot Surface. Install the fixture
at least 6" (Inches) away from wall, curtains and combustible
materials. Maintain at least 9" (Inches) of clearance directly in
front of the fixture.
AVERTISSEMENT: Risque du feu.
Surface Chaude.
Installez le montage au moins 6" (Pouces), 153 mm, loin du
mur, des rideaux et des matériaux combustibles. Maintenez au
moins 9" (Pouces), 230 mm, de dégagement directement
devant le montage.
1
1B
4
2
3
3
2
1
5
4
4
