LBL Lighting Merlino Swivel II - Manual

Installation Instructions for
Merlino Swivel II 1.3 HA300FRSC_1A50FSJ
980FSJMRLSII
1
NOTE: To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
Use Watt MR16 Front Cover MAX 50
Halogen Lamp.
G P I : ENERAL RODUCT NFORMATION
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
Align the lamp pins with the socket holes.
Push the lamp pins completely into the socket holes.
Install the Lamp and Shade
LAMP
SOCKET
Remove the three thumb screws.
THUMB SCREW
Fusion Jack
™
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1A
3
WARNING: Risk of Fire. Hot Surface. Install the fixture
at least 6" (Inches) away from wall, curtains and combustible
materials. Maintain at least 9" (Inches) of clearance directly in
front of the fixture.
AVERTISSEMENT: Risque du feu. Surface Chaude.
Installez le montage au moins 6" (Pouces), 153 mm, loin du
mur, des rideaux et des matériaux combustibles. Maintenez au
moins 9" (Pouces), 230 mm, de dégagement directement
devant le montage.
1
1B
2
3 3
