LBL Lighting Vent H User Manual
Vent head, Install the lamp, Remove the tail (optional)
1
Installation Instructions for
Vent Head
1.1
HD475_50FSJ
980FSJVENTH
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for indoor dry locations only.
Install the Lamp
LAMP
Use
Watt MR16 Front Cover
MAX 50
Halogen Lamp
Align the lamp pins with the socket holes.
Push the lamp pins completely into the socket holes.
NOTE:
Use only your fingers and a soft cloth to install
the lamp.
SOCKET
Remove the Tail (Optional)
TAIL
The tail can be removed for a different aesthetic.
Simply unscrew the tail by hand to remove it.
Fusion Jack
™
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
