LBL Lighting Tube 1 P User Manual
Tube 1, Connect the fixture arm

Installation Instructions for
Tube 1
1.2
HS2931FR_1B35MRL
980MRLTUB1P
G
P
I
:
ENERAL RODUCT NFORMATION
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
This product is intended to be used with LBL Monorail system.
1
(H)
Connect the Fixture Arm
The overall fixture height (H) is measured from bottom of the
glass shade to the end of the fixture Fusion Jack. Determine
the overall desired fixture height.The overall fixture height (H)
is 39" inches when the fixture rods are not cut.
GLASS SHADE
FIXTURE
FUSION
JACK
Mark amount (L) from one end of the fixture rod that needs to
be cut shorter. (Optional)
M3 SET
SCREW
1.6 MM
ALLEN
WRENCH
SOCKET PIN HOLE
Loosen
the two M3 set screws on the
(Do Not Remove)
socket assembly rods that are located on the opposite side of
socket pin holes.
(L)
FIXTURE ROD
NOTE:
To avoid interference while relamping do not
cut the fixture rods (L) more than 24" inches.
Cut the fixture arms with a sharp cutter. (Optional)
1A
1A
1
2
3
4
1A
1B
1A
1C
Monorail
3
2
4
4
