LBL Lighting Stogie II P User Manual
Stogie ii, Adjust the fixture height, Installation instructions for

Installation Instructions for
Stogie II
980FSJSTGIIP
1
GLASS SHADE
SOCKET ASSEMBLY
FIXTURE COAXIAL
CABLE
SET SCREW
Back out (do not remove) the set screw on tip of the
connector with the provided Allen wrench.
ALLEN WRENCH
3
Back out (do not remove) the set screw on the conical
connector with the provided Allen wrench.
SET SCREW
ALLEN WRENCH
4
1B
1C
4
3
CONNECTOR
1A
Feed the fixture coaxial cable through the glass shade. Slide the
glass shade down the cord and rest it onto the socket
assembly.
Cut the coaxial cable to the desired length.
1
2
Adjust the Fixture Height
GENERAL PRODUCT INFORMATION:
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
Fusion Jack™
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
1.3
HS235_
1.5
HS270_
