GENERAL PRODUCT INFORMATION:
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
Fusion Jack™
Installation Instructions for
Visions 1.4 HS336_1A35FSJ
980FSJVISNP
1
Install the Lamp and Disk
LAMP
SOCKET
Align and push the lamp pins completely into the socket holes.
Orient the recessed section of the crystal glass disk toward
the lamp. Place edge of the crystal disk into curved section of
accessory springs.
Use MAX 35 Watt MR11 Front Cover Halogen
Lamp .
CURVED
SECTION
CRYSTAL
GLASS DISK
ACCESSORY
SPRINGS
CURVED
SECTION
NOTE: The Crystal disk must be removed when relamping.
NOTE: To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
1A 1B
1
2 2
1
2
2
2
2
