LBL Lighting Paperweight P User Manual
Paperweight, Adjust the fixture height

G
P
I
:
ENERAL
RODUCT NFORMATION
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
Fusion Jack
™
Installation Instructions for
Paperweight
1.4
HS349_
980FSJPPRWP
Adjust the Fixture Height
GLASS SHADE
SOCKET ASSEMBLY
FIXTURE COAXIAL
CABLE
1
ROD
CAP
Feed the fixture coaxial cable through the glass shade. Slide the
glass shade down the cord and rest it onto the socket
assembly.
Cut the coaxial cable to the desired length.
1A
1
SET SCREW
Back out (do not remove) the set screw on tip of the
connector with the provided Allen wrench.
ALLEN WRENCH
3
Back out (do not remove) the set screw on the conical
connector with the provided Allen wrench.
SET SCREW
ALLEN WRENCH
4
1B
1C
4
3
2
CONNECTOR
