Install the Lamp
Push the suction cup onto the lamp front cover.
LAMP
NOTE:
To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
Use
Watt MR16 Front Cover
MAX 35
Halogen Lamp.
SUCTION CUP
Align the lamp pins with socket holes.
Push the lamp pins completely into the socket holes.
SOCKET
Remove the suction cup by pulling on the tab.
SUCTION CUP
TAB
LAMP
SUCTION CUP
2A
2B
2C
1
2
4
2
1
3
4
