LBL Lighting Icicle P User Manual
Icicle, Install the lamp & shade, Installation instructions for

THUMB
SCREW
Installation Instructions for
Icicle
1.2
HS277_
980FSJICCP
1
Install the Lamp & Shade
1
LAMP
SOCKET
Use
Watt,Type Xelogen
MAX
35
(Xenon) Bi-Pin Lamp.
Push the lamp pins completely into the socket holes.
NOTE:
To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
NOTE:
Use only your fingers and soft cloth to replace
the lamp.
WARNING: RISK OF FIRE
Never replace a Xenon (Xelogen) lamp with a regular
Halogen lamp.A regular Halogen lamp requires a protective
glass shield.
Remove the three thumb screws.
1
GLASS SHADE
THUMB SCREW
BRACKET POST
Place the glass shade completely into the bracket post and
tighten the three thumb screws to secure the glass shade in
place.
NOTE:
Do not over tighten the thumb screw which may
cause the glass shade to break.
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
