LBL Lighting Dahling User Manual
Dahling pendant, Assemble the fixture

Installation Instructions for
1
Dahling Pendant
980FSJDHLNG
GENERAL PRODUCT INFORMATION:
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
Fusion Jack™
1.1
HS616_
SOCKET
LAMP
1A
NOTE:
Use only your fingers to install the lamp.
Push the lamp pins completely into the socket holes.
Use
MAX 50 Watt
Type Xelogen
(Xenon) Bi-Pin Lamp.
1
CAUTION: RISK OF FIRE
Never replace a Xenon lamp with a regular Halogen lamp.
A Halogen lamp requires a protective glass shield.
Assemble the Fixture
Place the hardware inside the glass shade and install the
three mounting rods by screwing them in completely.
2
1B
2
MOUNTING ROD
MOUNTING ROD
GLASS
SHADE
