LBL Lighting Mini-Lily User Manual

Lily, Adjust the fixture height

background image

G

P

I

:

ENERAL

RODUCT NFORMATION

This product is ETL listed and suitable only for indoor dry locations

and approved for use at any height above the finished floor.

CAUTION - RISK OF FIRE

This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.

Fusion Jack

Installation Instructions for

Lily

1.2

HS378_

980FSJLLYP

Adjust the Fixture Height

1

Back out (do not remove) the set screw on tip of the
connector with the provided Allen wrench.

Back out (do not remove) the set screw on the conical
connector with the provided Allen wrench.

SET SCREW

ALLEN WRENCH

2

1A

1B

2

1

1C

Tap the conical connector on a hard surface with the set screw

facing down, so the plate inside drops into place.

SURFACE

Cut the coaxial cable to the desired length.

Gently twist the end of the coaxial cable between thumb and

forefinger.

4

PLATE

3

4

1D

5

SET SCREW

ALLEN WRENCH

1

CONNECTOR
