LBL Lighting Mini-Mason P - Manual

Adjust the Fixture Height
G P I : ENERAL RODUCT NFORMATION
This product is ETL listed and suitable only for indoor dry locations
and approved for use at any height above the finished floor.
Fusion Jack
™
1
Back out (do not remove) the set screw on tip of the
connector with the provided Allen wrench.
Back out (do not remove) the set screw on the conical
connector with the provided Allen wrench.
SET SCREW
ALLEN WRENCH
2
1A
1B
2
1
1C
Tap the conical connector on a hard surface with the set screw
facing down, so the plate inside drops into place.
SURFACE
Cut the coaxial cable to the desired length.
Gently twist the end of the coaxial cable between thumb and
forefinger.
4
PLATE
3
4
1D
5
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
SET SCREW
ALLEN WRENCH
1
CONNECTOR
Installation Instructions for
Mini Mason
1.1 HS574_
980FSJMMASONP
