Instructions
Outline
The MOP-GL12232D is controlled using a standard SED1520 compliant controller. The display is enabled
by pulling the Enable (E) pin high, communication to and from the device is controlled by pulling the
Read/Write (R/W) line high or low respectively, and the unit may be reset at power up by pulling the
reset (RST) line low. Using Register Select (RS), either the data register or command register is selected
by toggling RS high or low respectively.
Before any data is read or written, the status of the display controller should be read. This is
accomplished by setting RS low, R/W high, E high, and reading the status byte that appears on the data
lines. Each bit of the status word indicates a specific condition, outlined below.
Table 3: Status Bits
Bit
Description
Status
D0
Unused.
Unused.
D1
Unused.
Unused.
D2
Unused.
Unused.
D3
Unused.
Unused.
D4
Reset.
0:Normal, 1:Reset.
D5
Display On/Off.
0:Display On, 1:Display Off.
D6 Display Data Direction. 0: Counter-CW, 1: Clockwise.
D7
Busy status.
0:Ready, 1:Busy.
Instruction Table
Table 4: Parallel Instruction Table
Instruction
Control
Instruction Code
RS R/W DB7
DB6
DB5
DB4
DB3 DB2 DB1 DB0
Display On
0
0
1
0
1
0
1
1
1
1
Display Off
0
0
1
0
1
0
1
1
1
0
Display Start Line
0
0
1
1
0
Start Line
Set (X) Page
0
0
1
0
1
1
1
0
X Page
Set (Y) Address
0
0
0
Y Address
Status Read
0
1
Busy ADC On/Off Reset
0
0
0
0
Write Display Data
1
0
Write Data
Read Display Data
1
1
Read Data
Counter-CW Display Data
0
0
1
0
1
0
0
0
0
1
Clockwise Display Data
0
0
1
0
1
0
0
0
0
0
Static Drive On
0
0
1
0
1
0
0
1
0
1
Dynamic Drive On
0
0
1
0
1
0
0
1
0
0
Set Data Auto Write
0
0
1
1
1
0
0
0
0
0
End Data Auto Write
0
0
1
1
1
0
1
1
1
0
Reset
0
0
1
1
1
0
0
0
1
0
