26
8 Ordering
8.1 Part Numbering Scheme
Table 26: Part Numbering Scheme
LCD 0821 -R -V -E
1 2 3 4 5
8.2 Options
Table 27: Display Options
# Designator Options
1 Product Type LCD: Liquid Crystal Display
2 Display Size 0821: 8 columns by 2 rows
3 Colour
* NP: Standard (YG for LCD/ no filter for VFD)
-GW: Grey Text with Grey-White Background
-WB: White Text with Blue Background
-IY: Yellow-Green Text with Black Background (Inverse Display)
-R: Red Text with Black Background (Inverse Display)
4 Voltage
* NP: Standard Voltage
-V: Wide Voltage
5 Temperature
* NP: Standard
-E: Extended Temperature
*Note: NP means No Populate; skip this designator in the part number and move to the next option.
8.3 Accessories
Communication
Table 28: Communication Accessories
SCCPC5V
Serial Communication/5V Power
Cable
BBC Breadboard Cable
