8. Appendix: Specifications and Options
8.1 Specifications
Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature -20°C to +70°C -40°C to +85°C
Storage Temperature -40°C to +80°C -50°C to +85°C
Operating Relative Humidity 20 to 80% non condensing
Vibration (non-operating) 10 to 55 to 10 Hz (Frequency)
1.0 mm (Total Amplitudes)
30 minutes (Duration)
X, Y, Z each direction
Shock (Non-operation) 593 m/S², 10 mS
Electrical Specifications
Supply Voltage 4.75 - 5.25 Vdc (optional 8 – 15 VDC)
Supply Current (all dots on) 130 mA typical
Supply Current (power off) 9 mA typical
Supply Current (power up) Up to 250 mA inrush
Optical Characteristics
Number of Characters 40 (20 characters by 2 lines)
Matrix format 5 x 7 with underline
Display Area 70.8 x 11.5 mm XxY
Character Size
2.4 x 4.7 mm (XxY), not including
underline
Character Pitch 3.6 mm
Line pitch 6.1 mm
Dot Size 0.4 x 0.5 mm (XxY)
Dot Pitch 0.5 x 0.7 mm (XxY)
Luminance 350cd/m² (100fL) min.
Color of Illumination Bluish Green
