Specifications
Environmental Specifications
Electrical Specifications
Optical Characteristics
Standard Temp. Extended Temp.
Operating Temperature 0º to +50º C -20º to +70º C
Storage Temperature -20º to +70º C -40º to +85º C
Operating Relative Humidity 90% max non-condensing
15
Appendix
Hex numbers are specified in C language convention as 0xUL - where U is the upper nibble and L is the lower nibble. Eg:
0xFE is 1111 1110 in binary. This is equivalent to ULH or ULh as in the binary number
1111 1110
upper lower
nibble nibble
.....which would be FEH or FEh
Supply Voltage 4.75 - 5.25 Vdc (optional 7 - 15Vdc)
Supply Current 9mA typical
Backlight Supply Current 115mA typical
Number of characters 40 (20 Characters x 2 Lines)
Matrix format 5 x 7 with underline
Display area 82.20 x 18.20 mm (XxY)
Character size 3.20 x 5.55 mm (XxY), not including underline
Character pitch 3.70 mm
Line pitch 5.95 mm
Dot size 0.60 x 0.65 mm (XxY)
Dot pitch 0.65 x 0.70 mm (XxY)
LED Backlight life 100,000 hours typical
Color of illumination Yellow green
