Keypad Header
Figure 16: Keypad Header
Table 10: Keypad Pinout
Pin Function Pin Function
1 Gnd 7 Column 1
2 Row 1 8 Column 2
3 Row 2 9 Column 3
4 Row 3 10 Column 4
5 Row 4 11 Column 5
6 Row 5 12 Gnd/Vcc *
To facilitate user input, the LK202-25/VK202-25 provides a Keypad Interface Connector which allows a
matrix style keypad of up to twenty-five keys to be directly connected to the display module. Key
presses are generated when a short is detected between a row and a column. When a key press is
generated, a character specific to that key press is automatically sent on the Tx communication line. If
the display module is running in I²C mode, the “Auto Transmit Keypress” function may be turned off to
allow the key presses to remain in the buffer so that they may be polled. The character that is
associated with each key press may also be altered using the “Assign Key Codes” command. The straight
twelve pin header of the Keypad Interface Connector will interface to a variety of different devices
including the Matrix Orbital KPP4x4 keypad.
*Note: The Ground / +5V pin is toggled by the jumper to the right of the keypad connector. Jump pads 1 & 2 for
+5V or 2 & 3 for GND.
