7.7 Optical Characteristics
Table 29: Display Optics
Module Size 96.40 x 23.00 x 31.14 mm
Viewing Area 51.6 x 11.9 mm
Active Area 48.2 x 8.9 mm
Character Size 2.45 x 3.95 mm
Character Pitch 3.05 x 4.95 mm
Pixel Size 0.45 x 0.45 mm
Pixel Pitch 0.50 x 0.50 mm
Viewing Direction 12 O’clock
Viewing Angle -30 to +30 °
Contrast Ratio 3
Backlight Half-Life 50,000 * Hours
*Note: Operation above 40°C and/or 50% RH will decrease half-life.
8 Ordering
8.1 Part Numbering Scheme
Table 30: Part Numbering Scheme
LK -162 A -4T -USB -WB -E
1 2 3 4 5 6 7
8.2 Options
Table 31: Display Options
# Designator Options
1 Product Type LK: Liquid Crystal Display with Keypad Input
2 Display Size -162: 16 columns by 2 rows
3 Form Factor A: A form factor
4 Keypad Size -4T: Four Integrated Tactile Keys
5 Protocol
* NP: Standard Model
-USB: USB Only Model
6 Colour
* NP: Standard (Black Text with Yellow-Green Background)
-FGW: Black Text with Grey-White Background
-WB: White Text with Blue Background
-TCI: Tricolour Text with Black Background
7 Temperature
* NP: Standard
-E: Extended Temperature
*Note: NP means No Populate; skip this designator in the part number and move to the next option.
