54 Command Summary
Table 52: 9-Slice Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Upload a 9-Slice File 92 3 5C 03 \ ETX Short, Integer, Byte[]
See
9-Slice File Creation
Always
Upload a 9-Slice Mask 92 6 5C 06 \ ACK Short, Integer, Byte[]
See
9-Slice File Creation
Always
Display a 9-Slice 91 5B [ Short, Byte[4] None Never
Table 53: Animation Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Upload an Animation File 92 4 5C 04 \ EOT Short, Integer, Byte[]
See Animation File
Creation
Always
Display Animation 193 C1 ┴ Byte[4], Byte[] None Never
Delete Animation 199 C7 ╟ Byte None Always
Start/Stop Animation 194 C2 ┬ Byte[2] None Never
Set Animation Frame 197 C5 ┼ Byte[2] None Never
Get Animation Frame 196 C4 ─ Byte Byte Never
Table 54: General Purpose Output Command Summary
Name Dec Hex ASCII Parameters Response Remembered
General Purpose Output On 86 56 V Byte None Never
General Purpose Output Off 87 57 W Byte None Never
Set Start Up GPO State 195 C3 ├ Byte[2] None Always
Set LED Indicators 90 5A Z Byte [2] None Remember On
Table 55: Dallas One-Wire Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Search for a One-Wire Device 200, 2 C8, 02 ╚, SOT None Byte[14] Never
Dallas One-Wire Transaction 200, 1 C8, 01 ╚, STX Byte[3], Byte[] Byte[] Never
Table 56: Piezo Buzzer Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Activate Piezo Buzzer 187 BB ╗ Short[2] None Never
Set Default Buzzer Beep 188 BC ╝ Short[2] None Remember On
Set Keypad Buzzer Beep 182 B6 ╢ Short[2] None Remember On
