background image

50

Environmental Specifications

Table 62: Environmental Limits

Standard

Extended (-E)

Operating Temperature

0°C to +50°C

-10°C to +60°C

Storage Temperature

-10°C to +60°C

-20°C to +70°C

Operating Relative Humidity

Maximum 90% non-condensing

Electrical Tolerances

Current Consumption

Table 63: Current Consumption

Board

+

Backlight

+

GPOs

45mA

50 to 220 mA

20mA each maximum


Table 64: Backlight Current Draw

YG

GW & WB

220mA

50mA

Input Voltage Specifications

Table 65: Voltage Specifications

Standard

*

Wide Voltage (-V)

*

Extended Wide Voltage (-VPT)

4.75-5.25V

9.0-15.0V

9.0-35.0V

*Note:

Standard and Wide Voltage variants of the RS422 model should be powered from a local source only.

Optical Characteristics

Table 66: Display Optics

Module Size

180.00 x 65.00 x 30.5

mm

Viewing Area

132.2 x 39.2

mm

Active Area

127.16 x 33.88

mm

Pixel Size

0.49 x 0.49

mm

Pixel Pitch

0.53 x 0.53

mm

Viewing Direction

12

O’clock

Viewing Angle

-30 to +30

°

Contrast Ratio

3

Backlight Half-Life

50,000

Hours
