38
No Type Description Command Argument 1 Argument 2 Argument 3 Argument 4 Return string
9 Single Data
Request Returns
a string
containing readings
in %F.S. for all
available channels. SD NON String with current
reading in %F.S
for all channels.
If channel not
calibrated [*]
will be added
to the reading.
10 Turns ON/OFF the
16 bit check sum
transmission of
check sums with
the data packet.
MODE: 0 - OFF
1 - ON
CS MODE char
[0 - 1] *0 CS MODE
OK[CR][LF]
Ex: CS 0
OK[CR][LF]
11 Set TOTALIZER
start FLOW in
%F.S. TS CHANNEL
1 char. [1-4] VALUE
float
[0-105.0] TS CH VALUE
OK[CR][LF]
Ex: TS 2 5.0
OK[CR][LF]
12 Set TOTALIZER
stop VOLUME in
current volume
based E.U. TP CHANNEL
1 char. [1-4] VOLUME
[0-999999.8] TP CH VOLUME
OK[CR][LF]
Ex: TP 2 1000
OK[CR][LF]
13 Set TOTALIZER
MODE TM CHANNEL
1 char.
[1-4] MODE [0-1]
0- DISABLE
1- ENABLE ACTION
[0-2]
0 - NON
1- BUZER
2 - VALVE
CLOSE
TM CH MODE
ACTION OK[CR]
[LF]Ex: TM 1 1 2
OK[CR][LF]
14 Reset TOTALIZER
to ZERO TZ CHANNEL
1 char.
[1-4] TZ CH OK[CR]
[LF]Ex: TZ 2
OK[CR][LF]
15 Read TOTALIZER
VOLUME
Returns volume in
current E.U. TR CHANNEL
1 char.
[1-4] TOT#CH: VOL
EU[CR][LF]
TOT#2: 1005.5
L[CR][LF]
16 TOTALIZER Status
command Returns
current settings for
all available
channels (mode,
action, start flow) SCT NON SCT M M A A SF
SF[CR][LF]
Ex: SCT 1 1 2 2
2.5 5.0[CR][LF]
(for two channels
SDPROC)
17 Second TOTALIZER
Status command.
Returns current
STOP VOLUME
settings for all
available channels. STS NON STS VOL
VOL[CR][LF]
Ex: STS 1000.0
15000.0[CR][LF]
(for two channels
SDPROC)
18 Set ALARM MODE AM CHANNEL
1 char. [1-4] MODE [0-1]
0- DISABLE
1- ENABLE ACTION
[0-2]
0 - NON
1- BUZER
2 - VALVE
CLOSE
DELAY
In seconds [0 - 65535] AM
CH MODE
ACTION OK[CR]
[LF]Ex: AM 1 1
2 0 OK[CR][LF]
19 Set ALARM LOW
flow margin
in %F.S. AL CHANNEL
1 char.
[1-4] VALUE
float
[0-105.0] AL CH VALUE
OK[CR][LF] Ex: AL
2 5.0 OK[CR][LF]
GENERAL CONTROL COMMANDS
TOT
A
LIZER SETTINGS AND ST
A
T
US COMMANDS
ALARM SETTINGS AND
ST
A
T
US
COMMANDS
