Low Power Shift-Out IntelliHead
2
CONFIGURATIONS
These are the low power Shift-Out IntelliHead models. Each model includes the ability to read all 3
tracks of data and is supplied with a 5-pin Molex connector (51021-0500). The reader configurations
and available wire lengths are indicated in the table.
Part
Number
Description Wire
Length
21030028 Butterfly spring for 90/100mm swipe readers 125mm
21030031 Cantilever Arm, left 125mm
21030036 4.05mm beam arm for insert readers 125mm
21030041 Spring for 43mm rail 125mm
21044013 43mm reader, no covers 100mm
21045092 90mm reader, no covers 80mm
21047021 90mm Slim profile reader, no covers 125mm
REFERENCE DOCUMENTS
Magnetic Card Reader Design Kit Technical Specification, P/N 99821002
Triple Track ASIC With Shift-Out, 3V, Specifications, P/N 99875337
Shift-Out IntelliHead 3V & 5V User Manual, P/N 99875258
