SECTION 4. TROUBLESHOOTING GUIDE
REQUIREMENTS
• Personal Computer.
• Interface Cable, Host End = DB9 female, Part Number 22410302.
• AC adapter, P/N 64300090.
• MICRbase Program, P/N 22000021
• Sample checks, P/N 96530005.
• A small bottle of compressed air.
SET-UP
1. Plug DB25connector of the RS232 cable into the MICRImage Reader.
2. Plug the DB9 connector of the RS232 cable into the PC.
3. Power on the MICRImage Reader.
4. Run the MICRbase program on the PC.
5. Start trouble-shooting procedure at Step 00.
00 Check
LED
Check the status of the LED indicator:
◊ off, continue to step 01.
◊ green, continue to step 02.
◊ blinking red, continue to step 11.
◊ blinking green, continue to step 16.
◊ blinking red/green, continue to 12.
◊ red or orange, continue to step 17.
