101-Millimeter Compatible Swipe Reader
2
SPECIFICATIONS
IEC:
Meets or Exceeds
Requirements for:
IEC 1000-4-2 ESD (Electro Static Discharge)
IEC 1000-4-3 Radiated EMC Field (2X requirement)
IEC 1000-4-4 Electrical Fast Transient Burst requirement
(transmission on I/O cable)
Flammability Meets UL94V-0
Recording Method Two-Frequency Coherent Phase (F2F)
Speed Card speed through the unit may vary from:
2 to 125 in/s at 75 bpi (5.1 to 318 cm/s at 29.5 b/cm)
2 to 60 in/s at 210 bpi (5.1 to 152.4 cm/s at 82.7b/cm)
Power Requirements Single Track: 2.7 to 5.5Vdc at 1 mA, typical
Dual Track: 2.7 to 5.5Vdc at 2 mA, typical
3 Tracks: 2.7 to 5.5Vdc at 3 mA, typical
Output Signal Levels V
ol
= 0.4 VDC at 2 mA
V
oh
= V
cc
-0.5 VDC at -2 mA
Operating Temperature -30
o
C to 70
o
C
Operating Humidity 10% to 90% relative humidity
Life 300,000 passes Single Track
1,000,000 passes Multi-Track
MTBF Electronics 125,000 h
Dimensions Length: 4.0" (101.6 mm)
Height: 1.08" (27.4 mm)
Width: 1.62" (41.1 mm)
Cable Length,
Standard: Single Track: 20" (508.0 mm)
Dual Track: 20" (508.0 mm)
3 Track 20" (508.0 mm)
Consult Factory for other lengths
Connector See Section 2, Connectors
Colors available Black, Standard
Pearl White Available
