1
SECTION 1. FEATURES AND SPECIFICATIONS
The 101-millimeter OEM Swipe Reader has a TTL level interface and is designed for use in
retail, access control, and time and attendance environments. This Reader is in compliance with
industry specifications, including ANSI/ISO Standards 7810, 7811-1 through -6, 7812, 7813, and
AAMVA. The Reader can be customized. Bidirectional read capability is available.
CONFIGURATIONS
Part Number Read Color Cable Length
Integral Electronics,
Single Track with Cover
21050001
21050002
21050003
Track 1
Track 2
Track 3
Black
Black
Black
20”
20”
20”
Integral Electronics,
Single Track without Cover
21050058
21050057
Track 1
Track 2
Black
Black
7”
21”
Integral Electronics,
Dual Tracks with Cover
Dual Tracks with Cover
21050004
21050005
Tracks 1 & 2
Tracks 2 & 3
Black
Black
20”
20”
Integral Electronics,
3 Tracks with Cover
21050145 Tracks 1,2, & 3 Black 20”
REFERENCE DOCUMENT
I/O Interface for TTL Swipe Readers, Technical Reference Manual, P/N 99875148
