MagTek 101-MILLIMETER COMPATIBLE - Manual (Page 2)

ii
Copyright
©
1989 - 2005
MagTek
®
, Inc.
Printed in the United States of America
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose,
without the express written permission of MagTek, Inc.
MagTek is a registered trademark of MagTek, Inc.
REVISIONS
Rev Number Date Notes
1 1989 Initial Release
2 22 Oct 99 Formatted manual; Added IEC requirements to
Specifications; Changed values in Specifications;
Clarified Connector information; Added correct
drawings; Clarified Card Present Signal
3 14 Sep 00 Section 1, Specs Corrected length dimension to
101.6 mm. Written to SI, International System of
Units.
4 25 Jul 01 Front Matter: Added to Agency page: FCC Class
B, UL and CUL, CE Class B. Copyright 2001
added.
5 08 Apr 03 Front Matter: added ISO line to logo, changed
Tech Support phone number, added new
warranty, changed warranty from 90 days to 1
year.
6 16 Jul 03 Sec 1: added cable length to Configuration Table
and deleted P/N 21050149 and added 21050005,
added MTBF Electronics to Specification Table,
changed power requirements to 2.7 VDC, and
corrected units. Table 2-1, 2-2, and 2-3 added
mating connectors and changed V
cc
from 2.4 to
2.7. Table 2-1 corrected color-coding for pin 6.
