Switch C
Switch C, Table 4-3, is used to define the way a card is read. The default for Switch C is:
01010101 Enable (but don’t require) tracks 1, 2 & 3; decode all types of tracks
Table 4-3. Switch C
Command position 1 2 3 4 5 6 7 8
Byte Position 7 6 5 4 3 2 1 0 Description
0 0 Track 1 Disabled
0 1 Track 1 Enabled
1 1 Track 1 is required*
0 0 Track 2 Disabled
0 1 Track 2 Enabled
1 1 Track 2 is required*
0 0 Track 3 Disabled
0 1 Track 3 Enabled
1 1 Track 3 is required*
0 Decode ISO/ABA tracks only
1 Decode ISO/ABA & custom tracks
X Reserved
* If a track is required but does not exist, the Reader will indicate an error for that track.
Sentinel Definitions
The start and end sentinels values can individually be specified by commands. The default
settings are shown in the Table 4-4.
Note
Changing the value of any of the sentinels does not actually
change the encoded value on the magnetic track; it merely
represents the sentinel in a unique way to help distinguish
differently formatted tracks.
Table 4-4. Start and End Sentinels
Value
Name Default
(hex)
Default
(ASCII)
Definition
S1 25 % Start Sentinel ISO/ABA Track 1
S2 3B ; Start Sentinel ISO/ABA Track 2
S3 2B + Start Sentinel ISO/ABA Track 3
S4 40 @ SS Non-standard (7bits) Track 2
S5 26 & SS Non-standard (7bits) Track 3
S6 23 # SS AAMVA track 3
SE 3F ? End Sentinel for all tracks all type
