6.2 Dysfunctions
The main dysfunctions are indicated by position lights :
Light “Status of the shrink fit unit” :
Switched off : The shrink fit unit is switched off
Check that the main switch (A6) is in position 1
Check that the unit is connected to the electric network and
is receiving power
fixed : The shrink fit unit is switched on
flashing : There is a default of voltage, at least one phase is not receiving
power
Check the connection of the socket
Check the fuses of the electric network
Light « Blocking of the shrink fit unit”
fixed : The maximum time allowed for heating or the maximum
temperature of the tool holder has been reached :
The unit is unusable for 30 seconds
Cooling completely the tool holder before any further
attempt.
light « default »
fixed : The electronic card is overheating
flashing : The inductor is overheating
Switch the unit off (main switch (A6) on position “0”) for 60
minutes.
This default may be due to intensive use or misuse of the shrink fit unit (use not
in compliance with the instructions).
Fast flashing : The heating cycles are too close (normal use is one cycle every
30 seconds)
