6
GUIDE TO THE COOKTOP
PLATE PVG4.0ZpZtR / PGX 6610
fig.1
TECHNICAL DATA
- heigh 87 mm
- depth 500 mm
- width 580 mm
- weight of the cooker 6,5 kg
1,2,3 - surface burners
4 - surface burner knobs
5 - grid
The cooker is equipped with burners:
1 - large burner, heat load
- 2,8 kW
2 - small burner, heat load - 1 kW
3 - medium burners, heat load - 1,8 kW
Appliance class:II
2H3+
The cooker is equipped with a pipe terminal - 1/2” ISO 228-1
1
2
3
4
5
3
5
4
4
4
