AMICA ZZM616W EN User Manual
Page 5
For getting the best performance from your dishwasher,Please read all operating instructions
before using it for thefirst time.
11
12
Back View
13
1
2
3
4
5
6
7
8
9
10
o n
Of f
Front view
3
Main Filter
5
Detergent Dispenser
6
Cup Shelf
7
Silverware Basket
8
Coarse Filter
9
Rinse Aid Dispenser
10
Inlet pipe connector
12
Drain pipe connector
11
Lower Basket
3
Spray Arms
2
Upper Basket
1
Water Softener
4
13
Tray ass.
Power
Start
R ese t
Inte nsive
Normal
Eco
Rins e
Rapid
3 In 1
7 Start / Reset Button: Press this button to start or pause the
dishwasher, the process pilot lamp will be on when
starting.
2 Power Light : To be on when the ON/OFF Button is
Pressed down.
5
4 Salt Warning Light : To be on when the softener
needs to be refilled.
3 Rinse Aid Warning Light : To be on when the
rinse aid dispenser needs to be refilled.
1 ON/OFF Button: To turn on/off the power supply.
Washing Program Selector: Turn the knob to select wash cycles
6
Program indicator light.
1
2
3
4
5
6
7
