AMICA ZIA 648 - Manual

QUICK REFERENCE GUIDE GB
Programme Table
Programme number 1 2 3 4 Reference* 5 6 7 8
Programme name
Cleaning temperature
Degree of Soiling Suitable for
removing the
remnants on the
soiled dishes that
will be kept waiting
in the machine for a
few days, and thus,
for preventing the
bad odor buildup.
Suitable for lightly
soiled daily dishes
that are scraped or
pre-cleaned.
Suitable for dishes
that are not pre-
cleaned but washed
immediately.
Most economical
washing program for
the medium soiled
daily dishes that are
kept waiting.
Daily washing program at
which the medium soiled
dishes that are kept
waiting are cleaned in the
fastest way.
Suitable for heavily
soiled dishes, pots
and pans.
Suitable for the dishes which
require extra hygiene such
as articles for babies. Also
suitable for heavily soiled
dishes.
Determines the soiling
degree of the dishes and
sets the temperature
and amount of the
washing water as well
as the washing time
automatically. Suitable for
all types of dishes.
- Few Few Medium Medium High High Medium to high
Detergents
A=25 cm³/15 cm³ B=5 cm³
- A A A+B A+B A+B A+B A
Programme sequence
(without options)
Pre-wash
▼
End
Wash
▼
Cold rinse
▼
Hot Rinse
▼
End
Pre-wash
▼
Wash
▼
Cold rinse
▼
Hot Rinse
▼
Dry
▼
End
Pre-wash
▼
Wash
▼
Cold rinse
▼
Hot Rinse
▼
Dry
▼
End
Wash
▼
Cold rinse
▼
Hot Rinse
▼
Dry
▼
End
Pre-wash
▼
Wash
▼
Cold rinse
▼
Hot Rinse
▼
Dry
▼
End
Pre-wash
▼
Wash
▼
Cold rinse
▼
Hot Rinse
▼
Hot Rinse
▼
Dry
▼
End
The programme
sequence is adjusted to
the amount of soiling
Duration (min) 15 30 71 155 60 136 124 78-156
Water (I) 4 10,2 13,2 13 10,2 14,8 17,8 10,4-14,0
Energy (kWh) - 0,75 0,9 1,02 1,24 1,45 1,97 0,90-1,45
Left-on mode / Off mode (W) *** 1.00 / 0.20
The consumption values shown in the table were determined under standard conditions. Differences may therefore occur under practical conditions.
* Reference programme for testing institutes The tests in accordance with EN 50242 must be carried out with a full water softener salt dispenser and a full rinse aid reservoir, and using the test programme. *** Power
consumption in off-mode and left-on mode are measured according to EN 50564:2011.
! Attention:Please read the operating manual prior to operating the machine for the first time.
How to use your dishwasher:
Open the water tap. •
Plug to the mains. •
Open the door and load the dishwasher. Check if both upper •
and lower spray arms move freely.
Pour (Put in) the detergent. •
Push in the on/off button and check that the display lights •
comes on. Check the salt and rinse aid level indicators before
you start the machine. If necessary add salt and rinse aid.
Use the programme selection button to choose your washing •
programme.
You may use Half Load/Combi Tablet button - Delayed Start •
Button features as necessary.
Start the programme with the Start / Cancel button: •
Close the door then programme starts. •
Attention
Avoid opening the door during the washing process. This interrupts
the washing process, and hot steam will escape. When the door is
closed, the programme will continue.
When the program you have selected comes to an end, an •
audible warning signal with intervals of 8 seconds will warn you
to turn off your machine. This audible signal will warn you 10
times before it turns off. Open the door Press the on/off button
after the programme is completed. The indicator lights will go off.
Close the water tap. Pull out the plug. •
Leave your dishes in the machine for about 15 minutes after they •
are washed in order to have them cooled down. Your dishes will
dry in a shorter time if you leave the door of your machine ajar
during this period. This will increase the drying effectiveness of
your machine.
8
9
10
11
12
13
Remaining Time Indicator/
Delay Time Indicator
Combi Tablet indicator
Programme indicator
Half Load/Combi Tablet button
Rinse aid level indicator light
Programme selection button
Half Load indicator
Salt indicator
On/Off button 1
2
3
6
7
4
5
Start/Cancel indicator
Time Delay indicator
Start/Cancel button
Time Delay button
- 50°C 40°C 35°C 65°C 70°C 60°C 40°C - 65°C
Pre-wash Delicate Economy Daily 60minA Intensive Auto Mini 30'
