Technical specifications 9
General 9.1
Resistant technopolymer front and back cover, RAL7030
Extruded aluminium body and external slide
Epoxypolyester powder painting, RAL9002 colour
Stainless steel external screws
Supplied with instruction manual, desiccant bag,
accessories for camera and lens mounting
Mechanical 9.2
3 cable glands
PMMA window (BxH): Ø 72mm (2.8in)
Internal usable area (BxH): 82x62mm (3.2x2.4in)
Internal usable length without accessories
HEK26 260mm (10.2in)
HEK30 300mm (11.8in)
Internal usable length with heater and/or power supply
HEK26 190mm (7.5in)
HEK30 235mm (9.3in)
Internal usable length with heater and/or blower
HEK26 190mm (7.5in)
HEK30 235mm (9.3in)
Electrical 9.3
Heater Ton 15°C+/-3°C (59°F +/-5°F) Toff 22°C+/-3°C
(71°F +/-5°F)
IN 12Vdc/24Vac, consumption 20W max -
IN 115/230Vac, consumption 40W max -
Blower with thermostat air filter, Ton 35°C+/-3°C
(95°F+/-5°F) Toff 20°C+/-3°C (71°F+/-5°F) and back cover
IN 12Vdc, consumption 4W max -
IN 24Vac, consumption 4W max -
Not compatible with bracket with internal cable channel
Camera power supply
IN 100-240Vac - OUT 12Vdc, 50/60 Hz, 1A -
IN 230Vac - OUT 24Vac, 50Hz, 400mA -
Environment 9.4
Indoor / Outdoor
Operating temperature with heater: -20°C / +50°C
(-4°F / +122°F)
Compliance to 9.5
CE according to EN61000-6-3, EN 60065, EN50130-4
IP66 according to EN 60529 with cable glands
IP66 according to EN 60529 with special gasket and
bracket with internal cable channel
IP54 according to EN 60529 with bracket with internal
cable channel
Maintaining and cleaning 7
Window and plastic 7.1
cover cleaning (PC)
Surface dirt should be rinsed away with water and
then the window cleaned with a neutral soap diluted
with water, or specific products for spectacle lens
cleaning. These should be applied with a soft cloth.
Avoid ethyl alcohol, solvents, h
hydrogenated hydrocarbide, strong
acid and alkali. Such products may
irreparably damage the surface.
Disposal of waste 8
materials
This symbol mark and recycle system n
are applied only to EU countries
and not applied to the countries
in the other area of the world.
Your product is designed and manufactured
with high quality materials and components
which can be recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed
of separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
