Kenwood KFC-WPS1300D - Manual (Page 40)

Technical Specifications
SIGN VALUE UNIT
Nominal Impedance Z 3+3 Ω
DC Resistance Re 2.6+2.6 Ω
Voice Coil Inductance Levc 0.7 mH
Piston Area Sd 0.0570 Sq.m
Force Factor BL 22 T.m
Volume Acoustic 55 liter
Compliance
Vas
1.945 cu.ft
Moving Mass Mms 270 g
Resonant Frequency Fs 30 Hz
Mechanical Q Factor Qms 4.03
Electrical Q Factor Qes 0.52
Total Q Factor Qts 0.46
Peak Excursion Xmax 13 mm
Peak Power Handring 2,000 W
RMS Power Handring 500+500 W
Sensivity (1 W/1 m) 82 dB
Displacement 13 CC
0.46 cu.ft
Mounting Depth 246 (9-22/32) mm (in.)
Weight of Magnet M 4,960 (175) g (oz.)
Voice Coil Diameter d 80 (3-5/32) mm (in.)
