Chapter 1. Introduction

4. SYSTEM RESET Button

Pressing and holding in this switch for more than three seconds

performs a system reset.

Note: This switch is semi-recessed and must be pushed with a thin

object—such as the end of a paper clip or a ballpoint pen.

5. USER PORT 1 Switch

This switch selects which USER PORT 1 is active—the one on the front
panel or the rear panel. Set it to FRONT to activate USER PORT 1 on the
front panel; set it to REAR to activate USER PORT 1 on the rear panel.

6. USER PORT 1 (Maintenance Port)

This port is provided for convenient and easy access for system
maintenance. It shares the same function with USER PORT 1 on the rear
panel. By switching the USER PORT 1 switch to FRONT, USER PORT 1
on the rear panel is deactivated and USER PORT 1 on the front panel is
activated. Use it just as you would any other user port. (You must return
the USER PORT 1 switch to the REAR position to reactivate USER PORT
1 on the rear panel.)
