FM tuner section
Frequency Range (50 kHz)
: 87.5 MHz – 108.0 MHz
Usable Sensitivity (S/N : 26 dB)
: 0.7 μV/75 Ω
Quieting Sensitivity (S/N : 46 dB)
: 1.6 μV/75 Ω
Frequency Response (± 3.0 dB)
: 30 Hz – 15 kHz
S/N Ratio (dB)
: 65 dB (MONO)
Selectivity (± 400 kHz)
: ≥ 80 dB
Stereo Separation
: 35 dB (1 kHz)
■
AM tuner section
Frequency Range (9 kHz)
LW
: 153 – 279 kHz
MW
: 531 – 1611 kHz
Usable Sensitivity
MW
: 25μV
LW
: 45μV
■
DAB section
(DNX521DAB, DNX4210DAB)
Frequency Range
L-BAND: 1452.960 – 1490.624 (MHz)
BAND III: 174.928 – 239.200 (MHz)
Sensitivity
: -100 dBm
S/N Ratio (dB)
: 80 dB
■
Degital Antenna Connector section
(DNX521DAB, DNX4210DAB)
Connector type
: SMB
Output Voltage (11 – 16V)
: 14.4 V
Maximum Current
: < 100 mA
■
Video section
Color System of External Video Input
: NTSC/PAL
External Video Input Level (Mini jack)
: 1 Vp-p/ 75 Ω
External Audio Max Input Level (Mini jack)
: 2 V/ 25 kΩ
Video Input Level (RCA jacks)
: 1 Vp-p/ 75 Ω
Video Output Level (RCA jacks)
: 1 Vp-p/ 75 Ω
Audio Output Level (RCA jacks)
: 1.2 V/ 10 kΩ
■
Audio section
Maximum Power (Front & Rear)
: 50 W x 4
Full Bandwidth Power (Front & Rear) (PWR DIN45324,
+B=14.4V)
: 30 W x 4
Preout Level (V)
: 2 V/ 10 kΩ
Preout Impedance
: ≤ 600 Ω
Speaker Impedance
: 4 – 8 Ω
Tone
Bass: 100Hz ± 8 dB
Middle: 1kHz ± 8 dB
Treble: 10kHz ± 8 dB
■
Navigation section
Receiver
: High-sensitivity GPS receiver
Reception Frequency
: 1575.42 MHz (C/A code)
Acquisition Times
Cold : 35 seconds (typ)
(On average for a stationary receiver with a clear
view of the sky)
Update Rate
: 1/second, continuous
Velocity : 0.05 m/sec. RMS
Accuracy
Position: <6 meters, typical
Velocity: 0.1 meter/sec RMS
Position Method
: GPS
Antenna
: External GPS antenna
■
General
Operating Voltage
: 14.4 V (10.5 – 16 V allowable)
Maximum Current Consumption
: 15 A
Installation Dimensions (W x H x D)
DNX521DAB, DNX521VBT
: 178 x 100 x 146 mm
DNX4210DAB
: 182 x 112 x 160 mm
Operational Temperature Range
: -10
°C – +60 °C
Weight
DNX521DAB, DNX521VBT: 2.3 kg
DNX4210DAB: 2.0 kg
NOTE
• Although the effective pixels for the liquid crystal
panel is given as 99.99% or more, 0.01% of pixels
may not light or may light incorrectly.
Specifications subject to change without notice.
