IMPORTANT

You must disconnect and lockout the electric supply
and the gas supply or the steam supply before any
covers or guards are removed from the machine to
allow access for cleaning, adjusting, installation, or
testing of any equipment per Occupational Safety
and Health Administration (OSHA) standards.

Please observe all safety precautions displayed on
the equipment and/or specified in the installation
manual included with the dryer.

CAUTION

The dryer(s) should never be left unattended while
in operation.

“Caution: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper
operation.”

«Attention: Au moment de l’entretien des com-
mandes, étiquetez tous les fils avant de les
débrancher. Des erreurs de câblage peuvent en-
traîner un fonctionnement inadéquat et dangereux.»

WARNING

Children should not be allowed to play on or near the
dryer(s). Children should be supervised if near
dryer(s) in operation.

Under no circumstances should the dryer door
switch(es), lint door/drawer switch(es), or heat safety
circuit(s) ever be disabled.

The dryer must never be operated with any of the
back guards, outer tops, or service panels removed.
Personal injury or fire could result.

The dryer must never be operated without the lint
filter/screen in place, even if an external lint collection
system is used.

FOR YOUR SAFETY

Do not dry mop heads in the dryer. Do not use
dryer in the presence of dry cleaning fumes.

The dryers must not be installed or stored in an
area where it will be exposed to water
and/or weather.

The wiring diagram for the dryer is located in the
front electrical control box area.

Table of Contents

Proposition 65

Use of this product could expose you to substances

from fuel combustion that contain chemicals

known to the State of California to cause cancer,

birth defects and other reproductive harm.

WARNING

!

SECTION I

SAFETY PRECAUTIONS ........................ 4

SECTION II

SPECIFICATIONS .................................. 6

SECTION III

INSTALLATION PROCEDURES ............. 8

A. Location Requirements ................................... 8
B. Unpacking/Setting Up ..................................... 9
C. Dryer Enclosure Requirements ...................... 11
D. Fresh Air Supply Requirements ..................... 12
E. Exhaust Requirements .................................. 13
F.

Electrical Information ..................................... 17

G. Gas Information ............................................. 20
H. Steam Information ......................................... 23
I.

Water Information .......................................... 27

J.

Preparation for Operation/Start-Up ................. 29

K. Preoperational Test ....................................... 30
L.

Preoperational Instructions ........................... 32

M. Compressed Air Requirements ...................... 32
N. Shutdown Instructions ................................... 33

SECTION IV

SERVICE/PARTS INFORMATION ........34

A. Service .......................................................... 34
B. Parts ............................................................. 34

SECTION V

WARRANTY INFORMATION................35

A. Returning Warranty Cards ............................. 35
B. Warranty ....................................................... 35
C. Returning Warranty Parts .............................. 35

SECTION VI

ROUTINE MAINTENANCE ..................37

A. Cleaning ........................................................ 37
B. Adjustments ................................................. 39
C. Lubrication .................................................... 39

SECTION VII

MANUAL RESET BURNER HI-LIMIT

INSTRUCTIONS ...................................40

A. Phase 7 ........................................................ 40
B. Dual Timer .................................................... 40

SECTION VIII

DATA LABEL INFORMATION...............41

SECTION IX

PROCEDURE FOR FUNCTIONAL

CHECK OF REPLACEMENT

COMPONENTS .....................................42
