Page 18
18
American Dryer Corp.
113360 - 8
2. Electrical Service Specifications
a. Gas and Steam Models Only
*
AWG Stranded Wire Type...size wire as per National Electrical Code or local codes.
9/5/08
** 3-Wire is available.
b. Electric Models Only
*
AWG Stranded Wire Type...size wire as per National Electrical Code or local codes.
9/5/08
** 3-Wire is available.
GAS AND STEAM
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.
When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK5 ONLY.
Calculate/determine correct fuse value, by applying either local and/or National Electrical Codes to listed
appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY. For others, calculate/verify
correct breaker size according to appliance amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3Ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
MINIMUM
WIRE SIZE
FUSING
CIRCUIT
BREAKER
Dual Element
Time Delay
60 Hz
50 Hz
208
3ш
3
28.3
—
*
50
50
230
3ш
3
—
31.9
*
50
50
240
3ш
3
26.7
—
*
45
45
380
3ш
3
16.2
—
*
25
25
380
3ш
4**
—
16.1
*
25
25
400
3ш
4**
—
16.1
*
25
25
416
3ш
4**
—
16.0
*
25
25
440
3ш
3
14.4
—
*
20
20
460
3ш
3
13.9
—
*
20
20
480
3ш
3
13.9
—
*
20
20
575
3ш
3
11.4
—
*
20
20
ELECTRIC (126 kW)
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.
When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK5 ONLY.
Calculate/determine correct fuse value, by applying either local and/or National Electrical Codes to listed
appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For others, calculate/verify correct breaker
size according to appliance amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3Ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
MINIMUM
WIRE SIZE
FUSING
CIRCUIT
BREAKER
Dual Element
Time Delay
60 Hz
50 Hz
416
3ш
4**
—
191
*
300
300
460
3ш
3
172
—
*
225
225
