Lint Trap Assembly
For Models Mfd. as of July 1, 2002
Illus. No.
Part No.
Qty.
Description
1
801070
1
Lint Trap Assembly Complete for 60 Hz Models ONLY
(includes illus. nos. 1 and 3 through 5)
800401
1
Lint Trap Assembly Complete for 50 Hz Models ONLY
(includes illus. nos. 1 and 3 through 5)
801069
1
Lint Trap ONLY (60 Hz)
800443
1
Lint Trap ONLY (50 Hz)
2
154200
6
5/32” Pop Rivet
3
150300
3
#10-16 x 1/2” Hex Washer TEK Screw
4
304100
1
Lint Screen Holder ONLY
5
800500
2
Lint Screen Assembly
